Dissolved Oxygen meter

Category: Dissolved oxygen meter

Applications: Dissolved oxygen online analyzer, an intelligent online chemical analyzer. The cap of the sensor is coated with a luminescent material. Blue light from an LED illuminates the luminescent chemical. The luminescent chemical instantly becomes excited and releases red light. The time and intensity of red light are inversely proportional to the concentration of oxygen molecules, So the concentration of oxygen molecules is calculated.

Get Quote Now

Specification :

Dissolved Oxygen Meter uses the latest Luminous Dissolved Oxygen measurement probes to provide reliable measurements for industrial and municipal applications. Dissolved Oxygen Meter use in a wide range of water analyzer solutions.

 Product  Dissolved Oxygen meter
 Measure range  0-20mg/L,0-200%,0-400hPa
 Resolution  0.01mg/L,0.1%,1hPa
 Accuracy  ±1.5%FS
 Temperature Type  NTC 10k/PT1000
 Auto A/manual H  -10-60℃ Resolution;0.1℃ Correction
 Output Type 1  4-20mA output
 Max.loop resistance  750Ω
 Repeatability  ±0.5%FS
 Output Type 2  RS-485 digital signal output
 Communication protocol  Standard MODBUS-RTU(customizable)
 Power supply  AC 220V±10%50Hz/60Hz

(optional 24V±10%)

 Alarm relay  AC 250V,3A



Application :

• Sewage treatment plants:

Oxygen measurement and regulation in the activated sludge basin for a highly efficient biological cleaning process

• Environmental protection water monitoring:

Oxygen measurement in rivers, lakes or seas as an indicator of the water quality

• Water treatment:

Oxygen measurement for status monitoring of drinking water for example (oxygen enrichment, corrosion protection etc.)

• Fish farming:

Oxygen measurement and regulation for optimum living and growth conditions

Instrument Selection :

Dissolved oxygen transmitter

Open a 92.5 * 92.5(mm) installation hole on the instrument cabinet or installation panel (the dimension is 100*100*150mm). Insert the instrument into the installation hole and latch on the butterfly clasp, as shown below.

Dissolved oxygen sensor
